Description
Application
Low profile design suitable for residential apartments and commercial service spaces
Design Specifications
- Wide pressed steel base with opal polycarbonate diffuser
- Quality white powder coated finish
- High efficiency LED optics, CRI >80, beam distribution 120°
- Integral constant current non-dimmable LED driver, with selectable power
- Selectable CCT 3000K / 4000K / 5700K
- Large terminal block for easy installation
Performance
- Dimmable - NO
| Model No. | Input Voltage | Multiple Wattage | Lumens | CCT | CRI | Beam Angle | Dim | Body Colour | IPART |
|---|---|---|---|---|---|---|---|---|---|
| SL9733/206TC/DP | 240 | 9/18 | 2100/2300/2200 | 3000/4000/5700 | 80 | 120 | 610(L) x 160(W) x 63(H) | WHITE | N/A |
| SL9733/212TC/DP | 240 | 18/36 | 3800/4150/3900 | 3000/4000/5700 | 80 | 120 | 1145(L) x 160(W) x 63(H) | WHITE | N/A |
| SL9733/215TC/DP | 240 | 28/55 | 5900/6350/6100 | 3000/4000/5700 | 80 | 120 | 1495(L) x 160(W) x 63(H) | WHITE | N/A |
