Description
Application
Energy efficient LED lamp solutions
Design Specifications
-
Fits new T8 LED fixtures or retrofit T8 fluorescent fixtures (Magnetic Ballast)
-
Traditional full glass shatter-proof poly coated body construction, G13 lamp base
-
High efficiency LED optics, CRI >80, beam distribution 320°
-
Integral non-dimmable LED driver, 9, 18 or 24 watt models
-
Selectable CCT 3000K / 4000K / 6000K
-
No flicker, instant start, Safety LED fuse included,
operating temp Min -20 / Max 25 deg C
Performance
- Dimmable - NO
| Model No. | Input Voltage | Power | Lumens | CCT | CRI | Beam Angle | Dimmable | Diameter | Length | Base Type |
|---|---|---|---|---|---|---|---|---|---|---|
| LT8/60TC | 240 | 9 | 900/1100/1000 | 3000/4000/6000 | 80 | 320 | NO | 28 | 589 | G13 |
| LT8/120TC | 240 | 18 | 1800/2200/2000 | 3000/4000/6000 | 80 | 320 | NO | 28 | 1198 | G13 |
| LT8/150TC | 240 | 24 | 2300/2500/2400 | 3000/4000/6000 | 80 | 320 | NO | 28 | 1500 | G13 |
