Description
Application
Perfect for any exterior space from residential small wattage designs through to high performance commercial applications
Design Specifications
-
Integral LED control gear, non-dimmable 70, 100, 150, 200, 250, 300 watt models, with selectable power
-
Robust black die-cast aluminium body profile with multi-function angled trunnion bracket, IK08, IP66 protection
-
Pre-wired with 1500mm UV rated flex for easy installation
-
CRI >80, selectable CCT 3000/4000/5000K
-
An impressive 140lm/W optical performance at 4000K
-
Tempered glass visor
| Model No. | Input Voltage | Power | Lumens | CCT | CRI | Beam Angle | Body Colour | Dim | Mass |
|---|---|---|---|---|---|---|---|---|---|
| SE7169MP70TC | 240 | 70 | 8400/9800/9100 | 3000/4000/5000 | 80 | 110 | Black | 280(L) x 55(W) x 246(H) | 2.55 |
| SE7169MP100TC | 240 | 100 | 12000/14000/13000 | 3000/4000/5000 | 80 | 110 | Black | 280(L) x 55(W) x 246(H) | 2.55 |
| SE7169MP150TC | 240 | 150 | 18000/21000/19500 | 3000/4000/5000 | 80 | 110 | Black | 310(L) x 55(W) x 345(H) | 3.77 |
| SE7169MP200TC | 240 | 200 | 24000/28000/26000 | 3000/4000/5000 | 80 | 110 | Black | 334(L) x 57(W) x 351(H) | 4.27 |
| SE7169MP250TC | 240 | 250 | 30000/35000/32500 | 3000/4000/5000 | 80 | 110 | Black | 435(L) x 63(W) x 395(H) | 7.3 |
| SE7169MP300TC | 240 | 300 | 36000/42000/39000 | 3000/4000/5000 | 80 | 110 | Black | 435(L) x 63(W) x 395(H) | 7.93 |
