Description
Application
Ideal for any commercial interior space looking for an economical lighting choice
Design Specifications
-
Premium aluminium body profile, CA90 rated
-
Stylish white powder coat finish
-
Quality opal polycarbonate diffuser
- High efficiency SMD LED chips
-
Remote constant current trailing edge dimmable LED driver, with flex and plug
Performance
Dimmable - YES
Dimmer Type - Trailing edge, optional 1-10V, DALI, DSI
| Model No. | Input Voltage | Multiple Wattage | Lumens | CCT | Beam Angle | Dimmable | CRI | Body Colour | Cut Out | Diameter | Dim | IPART | VEET |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S9073TC/SL/DP | 240 | 13/18 | 1400/1550/1550 | 3000/4000/5700 | 90 | YES | 80 | SILVER | 135 | 165 | 165(W) x 63(H) | ||
| S9073TC/WH/DP | 240 | 13/18 | 1500/1800/1600 | 3000/4000/5700 | 90 | YES | 80 | WHITE | 135 | 165 | 63(H) | YES | YES |
