Description
9 watt dimmable LED downlight, CRI80, with selectable CCT
Application
Perfect for residential or commercial applications
Design Specifications
-
9 watt remote flickerCONTROLLED dimmable driver, complete with flex & plug
-
High efficiency LED optics, recessed low glare optical system
-
Selectable CCT 3000K / 4000K / 5700K, CRI>80, 60° beam distribution
-
Polyamide covered aluminium body profile with PC trim
-
IC - 4 rated downlight and driver, double insulated
-
IP54 from below the ceiling, IP40 above
Performance
- Dimmable - YES
- Dimmer Type - TRAILING EDGE
| Dimmer Trailing Edge | YES |
|---|
| Model No. | Input Voltage | Power | Lumens | CCT | Beam Angle | Dimmable | CRI | Cut Out | Diameter | Dim |
|---|---|---|---|---|---|---|---|---|---|---|
| S9041R/TC2WH | 240 | 9 | 830/930/900 | 3000/4000/5700 | 60 | YES | 80 | 92 | 100 | 55(H) |
