SAL PANEL S9784U TC/DP2 LED Panels and Troffers Tri- White 30/50W 240V IP44 - S9784U612TC/DP2

Application

Designed for commercial and office space lighting tasks.

Design Specifications

• UGR<19 performance

• Extruded aluminium profile with high efficiency opal diffuser, suitable for a range of installation types

• White powder coat finish

• High efficiency LED optics, CRI >90

• FlickerCONTROLLED, remote constant current non-dimmable LED driver, complete with flex and plug

• Selectable CCT 3000K/4000K/5700K,

• Suspension kits available:

S97X4SP4

SSI1512

SSY1512

S97X4KIT

• Emergency models compliant to AS/NZS2293, see SEL20PK EM Power Kit.

Performance

• Dimmable - OPTIONAL
• Dimmer Type - trailing edge, 1-10V, DALI/DSI

Model No.	Input Voltage	Multiple Wattage	Lumens	CCT	CRI	Beam Angle	Body Colour	Dim
S9784U306TC/DP2	240	12/24	2250/2500/2400	3000/4000/5700	90	90	WHITE	595(L) x 295(W) x 32(H)
S9784U312TC/DP2	240	23/36	3400/3700/3600	3000/4000/5700	90	90	WHITE	1195(L) x 295(W) x 32(H)
S9784U612TC/DP2	240	30/50	4750/5250/5000	3000/4000/5700	90	90	WHITE	1195(L) x 595(W) x 32(H)
