Description
Application
Designed for commercial and office space lighting tasks.
Design Specifications
-
UGR<19 performance
-
Extruded aluminium profile with high efficiency opal diffuser, suitable for a range of installation types
-
White powder coat finish
-
High efficiency LED optics, CRI >90
-
FlickerCONTROLLED, remote constant current non-dimmable LED driver, complete with flex and plug
-
Selectable CCT 3000K/4000K/5700K
Suspended wire kits available
Emergency models compliant to AS/NZS2293 with D50 spacing classification available, see Interior Emergency section.
Performance
- Dimmable - OPTIONAL
- Dimmer Type - trailing edge, 1-10V, DALI/DSI
| Model No. | Input Voltage | Multiple Wattage | Lumens | CCT | CRI | Beam Angle | Body Colour | Dim |
|---|---|---|---|---|---|---|---|---|
| S9784U306TC/DP2 | 240 | 12/24 | 2250/2500/2400 | 3000/4000/5700 | 90 | 110 | WHITE | 595(L) x 295(W) x 32(H) |
| S9784U312TC/DP2 | 240 | 23/36 | 3400/3700/3600 | 3000/4000/5700 | 90 | 110 | WHITE | 1195(L) x 295(W) x 32(H) |
