SAL Panel MK II S9754 LED Panels and Troffers Tri- White 18/30/48W 240V IP20 - S9754

Save $9.16

SAL LightingSKU: S9754/306TC

Colour: 18W/ TRI COLOR (595L)

Price:

$82.42 $91.58

Tax included Shipping calculated at checkout

Quantity:

Designed for commercial and office space lighting tasks.

Extruded aluminium profile with high efficiency opal diffuser suitable for a range of installation types.
Quality white powder coated finish
High efficiency SMD LED chips, CRI > 80
Remote constant current non-dimmable LED driver, complete with flex and plug
Easy selectable colour temperature with an inbuilt DIP switch, 3000K / 4000K / 5700K for TC models
Suspended wire kits available, Emergency models compliant to AS/NZS2293 with D50 spacing classification available.

Dimmable - OPTIONAL

Dimmer Type - Trailing edge,1-10V (excluding S9754/612) , DALI / DSI

Model No.	Description	Input Voltage	Power	Lumens	CCT	CRI	Beam Angle	Body Colour	Dim
S9754/306TC	LED PANEL 18W 295 X 595 X 12mm 3/4/6K	240	18	1900/2000/2100	3000/4000/5700	80	100	White	595(L) x 295(W) x 12(H)
S9754/606TC	LED PANEL 30W 595 X 595 X 12mm 3/4/6K	240	30	3100/3200/3300	3000/4000/5700	80	100	White	595(L) x 595(W) x 12(H)
S9754/312TC	LED PANEL 30W 295 X 1195 X 12mm 3/4/6K	240	30	3000/3100/3200	3000/4000/5700	80	100	White	1195(L) x 295(W) x 12(H)
S9754/312TC/DIM	LED PANEL 30W 295 X 1195 X 12mm 3/4/6K DIM	240	30	3000/3100/3200	3000/4000/5700	80	100	White	1195(L) x 295(W) x 12(H)
S9754/612TC	LED PANEL 48W 595 X 1195 X 12mm 3/4/6K	240	48	5000/5200/5300	3000/4000/5700	80	100	White	1195(L) x 595(W) x 12(H)
S9754/306EM	LED PANEL 18W 295mm X 595 X 12mm EMERG.	240	18			80	100	White	595(L) x 295(W) x 12(H)
S9754/312EM	LED PANEL 30W 295 X 1195 X 12mm EMERG	240	30			80	100	White	1195(L) x 295(W) x 12(H)
S9754/612EM	LED PANEL 48W 595 X 1195 X 12mm EMERG	240	48			80	100	White	1195(L) x 595(W) x 12(H)
S9754/606EM	LED PANEL 30W 595 X 595 X 12 mm EMERG.	240	30			80	100	White	595(L) x 595(W) x 12(H)

DOWNLOADS

DATASHEET
INSTALLATION GUIDE
