Description
Application
A perfect choice for apartments or commercial spaces
Design Specifications
-
Selectable CCT 3000K / 4000K / 6000K
-
Durable powder coated steel body profile with a high performance opal PMMA diffuser
-
High efficiency LED optics, CRI > 80
-
Integral, non-dimmable LED driver with dual power selections and optional DALI²
-
Ceiling mount, two versatile profile sizes Ø 320 or 400mm
Performance
- Dimmable - OPTIONAL
- Dimmer Type - Trailing edge or DALI²
- In Built Sensor - OPTIONAL
- Sensor Type - MICROWAVE 40TC ONLY
| Model No. | Input Voltage | Multiple Wattage | Power | Lumens | CCT | CRI | Dimmable | Beam Angle | Body Colour | Diameter | Dim | Mass | IPART |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SO3700/30TC/DP2 | 240 | 8/16 | 1100/1400/1200 | 3000/4000/6000 | 80 | NO | 120 | White | 310 | 78(H) | 0.54 | YES | |
| SO3700/40TC/DP2 | 240 | 15/30 | 2350/2800/2400 | 3000/4000/6000 | 80 | NO | 120 | White | 390 | 102(H) | 0.86 | YES | |
| SO3700/40TC/DALI² | 240 | 30 | 2600/2900/2690 | 3000/4000/6000 | 90 | YES | 120 | White | 390 | 102(H) | 0.82 | N/A |
