Description
Application
Energy efficient LED lamp solutions, requiring daylight sensor functions.
Design Specifications
- Opal polycarbonate diffuser, beam distribution 200°
- Poly covered aluminium body, B22 and E27 lamp bases
- High efficiency LED optics, CRI>80
- Integral non-dimmable LED driver with fixed daylight sensor, 30 lux threshold, OFF delay 5 minutes.
- Selectable CCT 2700K/4000K/6500K
- 1:1 size to traditional GLS / A60 lamp, suits most GLS / A60 lamp fittings, double insulation
Performance
- Dimmable - NO
- In Built Sensor - YES
- Sensor Type - DAYLIGHT
| Model No. | Input Voltage | Power | Lumens | CCT | CRI | Beam Angle | Dimmable | Diameter | Length | Base Type |
|---|---|---|---|---|---|---|---|---|---|---|
| LGS10TC/B22/PC | 240 | 9 | 900/1000/950 | 2700/4000/6500 | 80 | 200 | NO | 60 | 112 | B22 |
| LGS10TC/E27/PC | 240 | 9 | 900/1000/950 | 2700/4000/6500 | 80 | 200 | NO | 60 | 112 | E27 |
