Description
Application
Home theatre, commercial spaces and decorative feature lighting designs which require smart control
Design Specifications
-
Designed for single colour brightness control, smooth 0 - 100% dimming
-
Input voltage range: 12-24V DC, 360W maximum power output at 24V
-
One channel with two sets of terminals for easy wiring
-
Supports momentary switch (bell press control)
-
Control button for easy commissioning and optional memory function
-
Supports both wireless and wired group control.
Dimming is achieved via the PIXIE or PIXIE PLUS app (strip controller if supplied) or via a SAL Multifunction control. Trailing edge dimmers are not suitable
Performance
- Dimmable - YES
- Dimmer Type - PIXIE Bluetooth control
| Model No. | Description | Input Voltage | Power | Dim | Dimmable |
|---|---|---|---|---|---|
| LT8915DIM/BT | LED STRIP CONTROLLER | 24 | 360 | 175(L) x 45(W) x 27(H) | YES |
