Description
Application
Ideal for any retail or commercial interior spaces
Design Specifications
-
Selectable CCT 3000K / 4000K / 5500K
-
Selectable power 15W/22W
-
Durable die-cast aluminium body profile, with white or silver trim
-
Remote, non-dimmable LED driver, with flex and plug
-
High efficiency LED optics with an opal polycarbonate diffuser
-
Do Not Cover rated, double insulated
Performance
- Dimmable - OPTIONAL
- Dimmer Type - Trailing edge, 1-10V, DALI / DSI
| Model No. | Description | Input Voltage | Multiple Wattage | Lumens | CCT | Beam Angle | Dimmable | CRI | Body Colour | Dimensions |
| S9522TC WH | LED D/L 22W 184mm 3/4/6K WHITE | 240 | 15/22 | 1500/2100 | 3000/4000/5500 | 100 | OPTIONAL | 80 | WHITE | 184(W) x 55(H) |
| S9522TC SL | LED D/L 22W 184mm 3/4/6K SL. | 240 | 15/22 | 1500/2100 | 3000/4000/5500 | 100 | OPTIONAL | 80 | SILVER | 184(W) x 55(H) |
