Description
Application
Ideal for any residential or commercial interior spaces
Design Specifications
- Durable die-cast aluminium body profile
-
Stylish powder coat finish in white or plated satin nickel
-
Versatile gimbal head with 30° tilt
-
High output LED optics, CRI > 80
-
Selectable CCT 3000K/4000K/5700K
-
Remote, trailing edge, dimmable LED driver with flex and plug, white surface mount options available, 145hm, x Ø152mm (S9046SM/TC/WH), IC - 4 rated, double insulated
Performance
- Dimmable - YES
- Dimmer Type - Trailing edge. Optional - 1-10V, DALI / DSI
| Model No. | Input Voltage | Power | Lumens | CCT | Beam Angle | Dimmable | CRI | Body Colour | Cut Out | Diameter | Dim | IPART | REES |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S9046SM/TC/WH | 240 | 9 | 800/800/850 | 3000/4000/5700 | 60 | YES | 80 | WHITE | 152 | 145(H) | N/A | N/A |
