Description
Application
Ideal for any residential or commercial interior spaces
Design Specifications
- Durable die-cast aluminium body profile
-
Stylish powder coat finish in white or plated satin nickel
-
Versatile gimbal head with 30 degree tilt, IC- 4 rated
-
High output LED optics, 60 Deg standard beam, CRI > 80
-
Remote constant current trailing edge dimmable LED driver with flex and plug
-
92mm cut-out
Performance
- Dimmable - YES
- Dimmer Type - Trailing edge, 1-10V, DALI / DSI
| Model No. | Input Voltage | Power | Lumens | CCT | Beam Angle | Dimmable | CRI | Body Colour | Cut Out | Diameter | Dim | IPART | REES |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S9046TC/WH | 240 | 9 | 800/800/850 | 3000/4000/5700 | 60 | YES | 80 | WHITE | 92 | 103 | 60(H) | N/A | N/A |
| S9046TC/SN | 240 | 9 | 800/800/850 | 3000/4000/5700 | 60 | YES | 80 | SATIN NICKEL | 92 | 103 | 60(H) | N/A | N/A |
