Description
Application
Conventional linear LED batten products for commercial or residential service spaces
Design Specifications
- 67 mm narrow steel body
- Quality white powder coat finish with robust opal polycarbonate diffuser
- Large terminal block for easy installation
- Selectable CCT 3000K/4000K/5700K
- High efficiency LED optics, CRI >80, 120° beam distribution
- Integral constant current non-dimmable LED driver with selectable power, emergency options available
Performance
- Dimmable - NO
| Model No. | Input Voltage | Power | Multiple Wattage | Lumens | CCT | CRI | Beam Angle | Dimmable | Dim | Body Colour |
|---|---|---|---|---|---|---|---|---|---|---|
| SL9731/40TC/DP | 240 | 40 | 20/40 | 4300/4900/4400 | 3000/4000/5700 | 80 | 120 | NO | 1200(L) x 67(W) x 68(H) | WHITE |
