Description
Application
A perfect choice for apartments or commercial spaces
Design Specifications
-
(4) four models to select 12, 18, 25 or 30 watt
-
Soft square architectural design, colour white with an opal polycarbonate diffuser
-
High efficiency LED optics, CRI > 80, CCT 4000K, optional 3000K and 5700K
-
Integral constant current trailing edge dimmable LED driver
-
Low profile design, IP54, designed for weather protected (under eave) installations, double insulated.
Performance
- Dimmable - YES
- Dimmer Type - Trailing edge
| Model No. | Description | Input Voltage | Power | Lumens | CCT | CRI | Body Colour | Dimensions |
| SL3247/25CW | LED OYSTER 12W SQ. IP54 4K WH | 240 | 12 | 1000 | 4000 | 80 | WHITE | 250(L) x 250(W) x 50(H) |
| SL3247/30CW | LED OYSTER 18W SQ. IP54 4K WH | 240 | 18 | 1600 | 4000 | 80 | WHITE | 300(L) x 300(W) x 40(H) |
| SL3247/35CW | LED OYSTER 25W SQ. IP54 4K WH | 240 | 25 | 2400 | 4000 | 80 | WHITE | 350(L) x 350(W) x 40(H) |
| SL3247/40CW | LED OYSTER 30W SQ. IP54 4K WH | 240 | 30 | 2500 | 4000 | 80 | WHITE | 400(L) x 400(W) x 50(H) |
