Description
Application
Perfect for residential or commercial applications
Design Specifications
- 9 watt integral flickerCONTROLLED dimmable driver, complete with flex & plug
- High efficiency LED optics, multi-faceted optical system
- Selectable CCT 3000K / 4000K / 5700K, CRI>90, 60° beam distribution, UGR<19
- Polyamide trim and body in white or black
- IC - 4 rated, double insulated UGR < 19
Performance
- Dimmable - YES
- Dimmer Type - TRAILING EDGE
| Model No. | Description | Input Voltage | Power | Lumens | CCT | Beam Angle | Dimmable | Dim |
|---|---|---|---|---|---|---|---|---|
| S9068TC/WH | LED D/L 9W IP44 TC WH DIM | 240 | 9 | 570/630/610 | 3000/4000/5700 | 60 | YES | 103(W) x 89(H) |
| S9068TC/BK | LED D/L 9W IP44 TC BK DIM | 240 | 9 | 570/630/610 | 3000/4000/5700 | 60 | YES | 103(W) x 89(H) |
