Description
Application
Conventional LED profile battens for commercial service spaces
Design Specifications
- Selectable CCT 3000K/4000K/5700K
- Extruded aluminium body with plastic end cap with a rear cable channel allowing easy wiring
- White powder coat finish
- Integral constant current non-dimmable LED driver, 25, 45 or 50 watt
- Robust opal polycarbonate diffuser
- High efficiency LED optics, CRI >80, 120° beam distribution
Performance
- Dimmable - NO
| Model No. | Input Voltage | Power | Lumens | CCT | CRI | Beam Angle | Dim | Body Colour |
|---|---|---|---|---|---|---|---|---|
| SL9709/60TC | 240 | 25 | 3400/3600/3600 | 3000/4000/5700 | 80 | 120 | 613(L) x 120(W) x 35(H) | WHITE |
| SL9709/120TC | 240 | 45 | 6100/6500/6500 | 3000/4000/5700 | 80 | 120 | 1213(L) x 120(W) x 35(H) | WHITE |
| SL9709/150TC | 240 | 50 | 6900/7300/7300 | 3000/4000/5700 | 80 | 120 | 1485(L) x 120(W) x 35(H) | WHITE |
