Description
Product Features:
- Input voltage range: 180-260V AC 50/60Hz
- Constant current LED driver included
- Material: aluminium & PC
- LED chips: SMD2835
- Power factor: >0.5
- PIR sensor type
- Max.detection diameter radius: 5m
- Time delay 90 seconds
- Detection range: 80°
- Block time: 0.2 seconds
- Not suitable for dimming
- Suitable for 2-way switching
- Ambient temp: -20 to 45°C
- Not suitable for dimming
- Suitable for 2-way switching
- IP rating: IP20
- Sensor operates Day and Night (No Manual Override)
- IC-F rated
Warranty
3 year replacement warranty
Model No.
MOTION1, MOTION2, MOTION3, MOTION4
| Code | Description | Kelvin(K) | Lumens(lm) | Watt | CRI | Beam | Dim | L(mm) | W(mm) | depth(mm) | C/out(mm) |
| MOTION1 | D/L LED FIXED MOTION SENSOR WH RND 3000K 10W 90mm IP20 ICF | 3000 | 800 | 10 | >80 | 80 | no | ø105 | 35 | ø90 | |
| MOTION2 | D/L LED FIXED MOTION SENSOR WH RND 3000K 15W 120mm IP20 ICF | 3000 | 1200 | 15 | >80 | 80 | no | ø145 | 46 | ø120 | |
| MOTION3 | D/L LED FIXED MOTION SENSOR WH RND 5000K 10W 90mm IP20 ICF | 5000 | 850 | 10 | >80 | 80 | no | ø105 | 35 | ø90 | |
| MOTION4 | D/L LED FIXED MOTION SENSOR WH RND 5000K 15W 120mm IP20 ICF | 5000 | 1250 | 15 | >80 | 80 | no | ø145 | 46 | ø120 |
