Description
Product Features
- Input voltage: 220-240V AC 50/60Hz
- Remote dimmable driver included
- Housing & heatsink: plastic & aluminium
- Diffuser: frosted PC
- Faceplate: PBT
- Power factor: 0.9
- Colour temperature changeable: 3000K/ 4000K/ 5700K in one fitting
- GALTRI01A-02A: CCT switch on driver
- GALTRI03-05: rear switch
- LED chips: SMD2835
- CRI: ≥80
- Flex & plug: 600mm
- Ambient temperature: -20 to 40°C
- Suitable for dimming
- Suitable for 2-way switching
- IP rating: IP44
- IC-4 Rated
- Suitable for use with sensors
Warranty
3 year replacement warranty
Model No.
GALTRI01A, GALTRI02A
Tested & Recommended dimmers:
- CLA: VELA
- CLIPSAL: 32E450TM & 32ELEDM
- HPM: CAT400T
-
DIGINET: MEDM & MMDM/RT
*Please check with Licenced electrician for Min and Max dimmer load
*May be compatible with other untested dimmers
| Part No. | Description | Kelvin(K) | Lumens(LM) | Watt | CRI | Beam | Dimm | Width(mm) | Depth(mm) | Cut out(mm) |
| GALTRI01A | D/L LED FIXED DIMM WH RND Tri 10W IP44 90mm 120D | 3000/ 4000/ 5700 | 750/ 850/ 750 | 10 | >80 | 120 | Yes | Ø113 | 40 | Ø90 |
| GALTRI02A | D/L LED FIXED DIMM WH RND Tri 12W IP44 90mm 120D | 3000/ 4000/ 5700 | 900/ 1020/ 900 | 12 | >80 | 120 | Yes | Ø113 | 40 | Ø90 |
