Description
The CLA TRKTRI03 is a 15W integrated LED track head for 3 Wire – Single Circuit track systems. The Black fitting combines selectable CCT, high CRI and dimming with a 36° standard beam, while an additional 60° lens is included for a wider distribution.
Key Features
- 15W Integrated LED track head
- Compatible with 3 Wire – Single Circuit Track
- Selectable 2700K / 4000K / 6000K
- Light output by colour temperature: 2700K — 1120lm; 4000K — 1260lm; 6000K — 1220lm
- CRI >90
- 36° beam with additional 60° lens included
- Dimmable
- 355° swivel and 90° tilt
- IP20 for interior applications
- 3-year replacement warranty
Suitable Applications
- Retail displays
- Residential interiors
- Commercial feature and accent lighting
Technical Specifications
| Specification | Detail |
|---|---|
| Brand | CLA Lighting |
| Model | TRKTRI03 |
| Track compatibility | 3 Wire – Single Circuit Track |
| Input voltage | 220–240V AC |
| Wattage | 15W |
| Light source | Integrated COB LED |
| Colour temperature | 2700K / 4000K / 6000K selectable |
| Lumen output by colour temperature | 2700K — 1120lm 4000K — 1260lm 6000K — 1220lm |
| CRI | >90 |
| Beam angle | 36° standard; additional 60° lens included |
| Dimming | Dimmable |
| Adjustment | 355° swivel / 90° tilt |
| IP rating | IP20 |
| Dimensions | 165mm wide × 192.5mm high |
| Finish | Black |
| Warranty | 3-year replacement warranty |
Important Compatibility Note
Compatible with 3 Wire – Single Circuit Track. It is not compatible with 4 Wire – 3 Circuit or magnetic track systems.
