Description
The Havit HV9723 19.2W/m high-density LED strip provides 1640 lumens per metre of 4000K cool white light. This 24V DC IP20 strip is designed for dry indoor linear lighting applications, with 240 SMD LEDs per metre. The narrow 10mm version features 25mm cutting increments.
Key Features
- 19.2W per metre integrated SMD LED strip
- 240 × 3528 LED chips per metre
- 4000K cool white — 1640 lumens per metre
- 24V DC constant-voltage operation
- IP20 rated for dry indoor use
- 10mm (W) × 2mm (H)
- 25mm cutting increments
- Maximum powered run: 5m per run
- Custom cut per metre or 30m bulk roll
- 3-year replacement warranty
Installation note: Havit requires the strip to be installed on an aluminium heat-dissipating surface or profile for warranty compliance. Maximum powered strip length is 5m per run; a 30m roll is supplied for cutting into separate powered runs, not one continuous 30m installation.
Technical Specifications
| Specification | Detail |
|---|---|
| Brand | Havit Lighting |
| Range | Havit High Density 240LED |
| Model | HV9723-IP20-240-4K-1 |
| Light source | 240 × 3528 SMD LEDs per metre |
| Wattage | 19.2W per metre |
| Input voltage | 24V DC |
| Colour temperature | 4000K |
| Light output | 1640lm per metre |
| Dimensions | 10mm (W) × 2mm (H) |
| Cutting increment | 25mm |
| Maximum powered run | 5m |
| IP rating | IP20 |
| Dimming | With a suitable compatible dimming driver/control system |
| Mounting | Aluminium heat-dissipating profile or suitable aluminium surface required |
| Supply options | Custom cut per metre or 30m roll |
| Warranty | 3-year replacement warranty |
