Description
Application
For use with dimmable leading or trailing edge dimmers
Design Specifications
- Overload and short circuit protection
- Overheating protection
- Safe no load operation
-
Dimmable with compatible trailing edge or leading edge dimmers
-
Wired complete with flex and plug
-
Minimum / Max loads -
LED 1 watt min / 20 watt max,
HALOGEN 20 watt min / 60 watt max,
Note: minimum load compatibility with a dimming device, may be subject to the inclusion of a load correction capacitor/s in the circuit.
Electrical class II, Do Not Cover
Performance
- Dimmable - YES
- Dimmer Type - TRAILING OR LEADING EDGE
| Model No. | Input Voltage | Frequency | Output Voltage (V/AC) | Power | Power Factor | Dimmable | Dim |
|---|---|---|---|---|---|---|---|
| MINI/P60 | 240 | 50 | 11.5 | 60 | 0.99 | YES | 109(L) x 43(W) x 24(H) |
