Description
Application
Ideal for any residential or commercial interior space, experiencing nuisance ripple induced flicker
Design Specifications
-
Combined with the SAL SDD400RS/BTAM rippleSHIELD dimmer, the rippleSHIELD Unifit series eliminates nuisance ripple induced flicker between 750-1050Hz once and for all, typically found in the QLD and NSW regions.
-
Remote rippleSHIELD dimmable LED driver, with smooth dimming performance down to 1.0% of light output, designed with flex & plug
-
High output LED optics, 3000K CCT, CRI>80
-
A comprehensive range of downlight trims are available, see MIX & MATCH model numbers
-
Double insulated
-
Need more info......slide to the FAQ's below
Performance
- Dimmable - YES
- Dimmer Type - dim only with SDD400RS/BTAM
| Model No. | Input Voltage | Power | Lumens | CCT | Beam Angle | Dimmable | CRI | Diameter | Dim | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| S9053WP/SFI | 240 | 9 | 700 | 3000 | 60 | YES | 80 | 50 | 60(H) | ||
| S9008WW/WH/SFI | 240 | 9 | 700 | 3000 | 60 | YES | 80 | MATT WHITE | 76 | 82 | 80(H) |
| S9008WW/BK/SFI | 240 | 9 | 700 | 3000 | 60 | YES | 80 | MATT WHITE | 76 | 82 | 80(H) |
| S9009WW/WH/SFI | 240 | 9 | 700 | 3000 | 60 | YES | 80 | MATT WHITE | 76 | 82 | 80(H) |
| S9009WW/BK/SFI | 240 | 9 | 700 | 3000 | 60 | YES | 80 | MATT BLACK | 76 | 82 | 80(H) |
