Description
Application
Smart lighting controls for residential and commercial applications
Design Specifications
-
Push button control for trailing or leading edge dimming, with soft start and soft off technology
-
Colour temperature selection functionality is achieved when used with compatible SAL downlights (S9842CS/WH)
-
Multiple-location dimming by connecting SDD350UM with any number of secondary dimmers SDD300US can be achieved.
-
Fit most popular switch plates, three complimentary mech caps provided, overheating and over current protection, full short circuit protection
-
Programmable minimum brightness level and memory function, compliant to AS/NZS60669.2.1
-
Supports ceiling sweep & exhaust fan < 60watt loads in leading edge mode only.
Performance
- Dimmable - YES
- Dimmer Type - Trailing & Leading edge
| Model No. | Input Voltage | Power | Dim | Body Colour |
|---|---|---|---|---|
| SDD350UM | 240 | 300 | 44(L) x 23(W) x 23(H) | WHITE |
Minimum load - 5 watt
DOWNLOADS
