Description
Application
A decorative architectural solution for commercial exteriors
Design Specifications
-
Robust die-cast aluminium body, durable black powder coat finish
-
Stainless steel allen screws
-
High efficiency LED optics
-
Integral constant current non-dimmable LED driver
-
Selectable CCT 3000 / 4000 / 5700K
-
UV stabilized opal polycarbonate diffuser, IK10, IP65 performance
Product selections compliant to AS/NZS2293 Emergency Lighting & Exit Signs are located in the exterior emergency section
Performance
- Dimmable - OPTIONAL
- Dimmer Type - TRAILING EDGE
- In Built Sensor - OPTIONAL
- Sensor Type - MICROWAVE
| Model No. | Input Voltage | Power | Lumens | CCT | CRI | Beam Angle | Diameter | Dim | Body Colour |
|---|---|---|---|---|---|---|---|---|---|
| SE7082TC/BK | 240 | 16 | 1100/1150/1100 | 3000/4000/5700 | 80 | 100 | 295 | 95(H) | BLACK |
DOWNLOADS
