Description
Application
Decorative residential exterior solution, ideal for gardens and decorative pathways
Design Specifications
- Die-cast aluminium body
- Stainless steel face panel & screws, clear tempered glass diffuser
-
High output LED optics 24V DC driver required
-
Beam angle 30º , optical adjustment between 50º~60º
-
PC installation canister included, pre-wqired 600 mm 2 core rubber flex
-
Suitable LED drivers, PLUTO 15DV, PLUTO 40DV, PLUTO 60DV, PLUTO 100/24V, IK08, IP67 performance
Performance
- Dimmable - NO
| Model No. | Description | Input Voltage | Power | Lumens | CCT | CRI | Beam Angle | Dim | Body Colour |
|---|---|---|---|---|---|---|---|---|---|
| S9338/3W/30 WW | LED3W24V WW W/CASE | 24 | 3 | 150 | 3000 | 70 | 30 | 130(W) x 115(H) | STAINLESS STEEL |
| S9338/3W/30 DL | LED3W24V DL W/CASE | 24 | 3 | 200 | 6000 | 70 | 30 | 130(W) x 115(H) | STAINLESS STEEL |
